- The turret features a Y axis and half-indexing, expanding the machining possibilities.
- The machine is equipped with the largest spindle motor in the series, enabling powerful cutting.
- Realizes „simultaneous hole machining at both ends“ and „simultaneous machining with 2 tools“ using superimposition control.
- Miyano’s unique control technology cuts non-machining time by 27% (compared to earlier equivalent Miyano product)
|Max. machining diameter of bar work||Ø 42 mm||Ø 42 mm|
|Max. workpiece length||100 mm||100 mm|
|Max. speed main spindle||6,000 min-1||6,000 min-1|
|Max. speed back spindle||5,000 min-1||5,000 min-1|
|No. turret stations||8 stations||8 stations|
|No. power-driven tools||8||8|
